Universal articulated arms safety guard for hydraulic press, with reversible opening direction. Practical and immediately adjustable. Designed for frequent changes of operation.
Protects the operator from direct contact with dangerous parts frontally segregated by the shield. Frontally attachable to the machine. Equipped with wide «visibility» reversible opening shield: vertical, horizontal, left or right, with position-release knob. Equipped with a safety microswitch.
Angular anchorage stirrup - in pressed steel
Articulated arms in tubular steel
Rubbing articulation with friction disc
Angular junction for vertical turnover of the shield
Main box with 180° rotation and safety microswitch with n.2 NC contacts - electrically interlocked
Shield-opening release knob
Shield structure in aluminum profile
Shield in plastic shockproof and oil-resistant material
